Explore the Genuine Saint Ferrer® Pipe Flange Gasket and Bolting Kit Styles





PFG #8 The GBK.jpg


“The Original Saint Ferrer® Flange Gasket and Bolt Kit”

The “GBK”

The Original Saint Ferrer® Flange Gasket and Bolt kit is selected by the savings minded who want component parts of an assembly specified, packaged, and shipped together. Distributor and stores buyers will enjoy the convenience of fewer part numbers, additional shelf space, and time saved pulling orders





PFG # 7The BK.jpg


“Saint Ferrer® Bolt Kit”

The “BK”

One who enjoys keeping their own assortment of pipe flange gasket and hexagon machine bolting varieties like the BK where combinations are limited only to your specific needs





PFG # 9The SK.jpg

“Saint Ferrer® Stud Kit”

The “SK”



Similar to the Saint Ferrer® BK, the SK contains continuously threaded stud bolting with two heavy hexagon nuts per stud instead of heavy hex head machine bolting. You might select stud bolting in high temperature and pressure applications or where high strain energy satisfies your design intent





PFG #11 The LK.jpg


 “Saint Ferrer® Lug Kit”

The “LK”

Lug-style butterfly valves with tapped holes do not require nuts for assembly. Pipe flange gaskets are not required either since the valve is manufactured with one molded in place. The LK is supplied with heavy hex head machine bolts only. The overall dimensions including thread length, is based on common configurations. Make sure you check with your valve manufacturer to include mating flange information to ensure our charts have the correct bolt length for a proper thread engagement





PFG #12 The WBK.jpg


“Saint Ferrer® Wafer Bolt Kit”

The “WBK”

Installed between two flanges, wafer style butterfly valves require a bolt and nut for assembly . A gasket is not required since the valve comes with a gasket molded in place . The WBK bolt length is based on common configurations. Make sure you check with your valve manufacturer to include mating flange information to ensure our charts have the correct bolt length


Saint Ferrer® Custom Flange Gasket and Bolt Kit” – Custom and Special

Utilize the power of our proprietary Saint Ferrer® Flange Component Estimator to determine bolt quantity, diameter, length, as well as gasket dimensions for a variety of flange x flange, flange x flanged valve, or other custom configuration




Component Kits and Strength Series

Standardized for your convenience



Saint Ferrer® kits are used to assemble a variety of flanged joint configurations. To keep it simple, each component kit was given a simple two or three letter identifier. This helps us communicate with one another. Study our chart below and know our kits. Scroll down the page to select the component kit by Saint Ferrer® Series






Pipe Flange Gasket & Bolting Product Line




High strength alloy steel performance in high and low pressure applications

The Saint Ferrer® HS Series contain ASME listed high strength alloy steel bolting, ASTM A193 Grade B7. These components are used to withstand elevated temperatures, when strain behavior is important, or to maximize joint preload performance. When combined with our line of pipe flange gasket materials and assembly reference guide, you have the materials and tools you need to get the joint Good and Tight






Low strength corrosion resistance and strain behavior

The Saint Ferrer® LSCRES Series contain ASME listed low strength stainless steel bolting, ASTM A193 Grade B8 or B8M Class 1. These components are used when corrosion resistance is a priority, or when material strain behavior is important. When combined with our line of pipe flange gasket materials and assembly reference guide, you have the materials and tools you need to get the joint Good and Tight








Low strength carbon steel is the economical choice in Class 150 and Class 300 low pressure, low temperature applications

The Saint Ferrer® LS Series contain ASME listed low strength low carbon steel bolting, SA A307 Grade B. These components are used when economy is the choice. When combined with our line of pipe flange gasket materials and assembly reference guide, you have the materials and tools you need to get the joint Good and Tight
